Automatic Horizontal Baler
Fully Automatic Balers · Sinobaler SHBA2-200 to SHBA2-1200
Fully automatic feeding, baling, wire tying and ejection. Outputs from 0.8 to 16 tonnes an hour.
POA — price on application
Enquire about this machine Client sign-in for prices
Got an old machine? Trade it in towards this one →
Not sure this is the right machine? Try our baler selector →
New machine with a 12-month warranty, serviced and supported by our own engineers.
Made to order: ask us about lead times, options, delivery and installation.
About this machine
For sites that want fully automatic baling of cardboard, paper, film, fibre and more. It automatically feeds, compresses, threads and twists the wire, ties, cuts the wire and ejects the bale, making it ideal for large volumes. PLC control keeps operation consistent and safe, and it is generally used for medium to large volumes of over a tonne an hour.
It suits paper and cardboard recycling facilities, carton manufacturers, printers, paper and fibre traders, MRFs, RDF plants and distribution centres.
Features
- Fully automatic compressing, strapping, wire cutting and bale ejection
- PLC control system
- One-button operation
- Adjustable bale length
- Cooling system for the hydraulic oil (air or water cooling available)
- Push-button electric controls and a touch screen for settings and reading parameters
- Horizontal cutter at the feed opening to stop material getting stuck
- Cyclone feeding device to extract material from small shreds into the baler
- Optional automatic feeding conveyor that starts and stops with the hopper level
- Optional de-jamming cylinder, oil heater for cold sites, and fluffer for dense material
Typical materials
Cardboard (OCC), paper, newspaper, cartons, biomass, natural fibre, hay and straw, film, PET bottles and other packaging.
Specification
| Manufacturer | Sinobaler |
|---|---|
| CE marking | CE marked by the manufacturer |
| Warranty | 12 months |
Models & specifications
| Model | SHBA2-200 | SHBA2-400 | SHBA2-600 | SHBA2-1000 A | SHBA2-1000 B | SHBA2-1200 A | SHBA2-1200 B |
|---|---|---|---|---|---|---|---|
| Feed opening (L × W) | 1200 × 500 mm | 1200 × 720 mm | 1500 × 1100 mm | 1600 × 1100 mm | 2000 × 1100 mm | 1800 × 1100 mm | 2000 × 1100 mm |
| Bale size (W × H, length adjustable) | 500 × 500 mm | 720 × 800 mm | 1100 × 800 mm | 1100 × 800 mm | 1100 × 800 mm | 1100 × 1100 mm | 1100 × 1100 mm |
| Bale weight (cardboard) | 40–100 kg | 200–350 kg | 350–700 kg | 400–800 kg | 400–800 kg | 600–1200 kg | 600–1200 kg |
| Output (cardboard) | 0.8–1.2 t/h | 2–3 t/h | 3–5 t/h | 5–9 t/h | 8–12 t/h | 9–13 t/h | 12–16 t/h |
| Motor power | 11 kW | 15 kW | 22 kW | 45 kW | 45 kW | 55 kW | 2 × 30 kW |
| Number of ties | 3 | 4 | 4 | 4 | 4 | 5 | 5 |
| Cycle time (unloaded) | 16 s | 14 s | 18 s | 16 s | 19 s | 20 s | 14 s |
| Machine weight (approx.) | 4000 kg | 7000 kg | 13000 kg | 17000 kg | 19500 kg | 19000 kg | 21500 kg |
Manufacturer's figures, which can change without notice. Bale weights depend on your material, and bale sizes don't allow for expansion after the bale is ejected. We'll confirm the exact specification with your quote.
