New Made to order
Manual-Tie Horizontal Baler
Semi-Automatic Balers · Sinobaler SHB1-400 to SHB1-1200
Semi-automatic horizontal baler for up to 3.5 tonnes an hour. Everything is automatic except tying.
POA — price on application
Enquire about this machine Client sign-in for prices
Got an old machine? Trade it in towards this one →
Not sure this is the right machine? Try our baler selector →
New machine with a 12-month warranty, serviced and supported by our own engineers.
Made to order: ask us about lead times, options, delivery and installation.
About this machine
Also known as a semi-automatic horizontal baler. It presses solid and hollow materials and is widely used by paper and cardboard recyclers, carton manufacturers, printers, textile recyclers, distribution centres, PET recycling plants and packaging companies.
It suits sites handling no more than 3.5 tonnes of waste an hour. Apart from tying by hand, everything is automatic: conveyor feeding, compressing, bale ejection and opening and closing the door.
Features
- Push-button electric controls
- Hydraulic exit door that lifts to release bales
- Automatic bale ejection at the press of a button
- Closed-end design for very dense bales, especially hollow products
- Cyclone feeding device for small shreds
- Bale exit island for collecting bales with a forklift
- PLC control system
- Optional automatic feeding conveyor
- Optional horizontal cutter at the feed opening
- Optional cooling system (air or water) for high ambient temperatures
Typical materials
Cardboard, paper, PET bottles, PP/HDPE containers, textile waste, film, packaging, fibre and disposable plastic tableware.
Specification
| Manufacturer | Sinobaler |
|---|---|
| CE marking | CE marked by the manufacturer |
| Warranty | 12 months |
Models & specifications
| Model | SHB1-400 | SHB1-600 | SHB1-800 | SHB1-1000 | SHB1-1200 |
|---|---|---|---|---|---|
| Feed opening (L × W) | 1200 × 750 mm | 1300 × 750 mm | 1300 × 1100 mm | 1500 × 1100 mm | 1500 × 1100 mm |
| Bale size (L × W × H) | 1000 × 750 × 750 mm | 1000 × 750 × 750 mm | 1200 × 1100 × 750 mm | 1250 × 1100 × 750 mm | 1300 × 1100 × 1100 mm |
| Bale weight (cardboard) | 150–250 kg | 200–300 kg | 300–450 kg | 400–550 kg | 700–900 kg |
| Bale weight (PET bottles) | 150–200 kg | 200–250 kg | 300–400 kg | 400–500 kg | 700–800 kg |
| Output (cardboard) | 0.8–1 t/h | 1–1.2 t/h | 1.5–2 t/h | 1.8–2.5 t/h | 2.5–3.5 t/h |
| Output (PET bottles) | 0.5–0.6 t/h | 0.6–0.8 t/h | 1–1.2 t/h | 1.2–1.6 t/h | 2–2.5 t/h |
| Motor power | 15 kW | 18.5 kW | 22 kW | 22 kW | 30 kW |
| Number of ties | 4 | 4 | 4 | 4 | 5 |
| Cycle time (unloaded) | 46 s | 47 s | 49 s | 68 s | 65 s |
| Machine weight (approx.) | 5000 kg | 6000 kg | 8000 kg | 9500 kg | 14000 kg |
Manufacturer's figures, which can change without notice. Bale weights depend on your material, and bale sizes don't allow for expansion after the bale is ejected. We'll confirm the exact specification with your quote.
