Tyre Baler
Tyre Balers · Sinobaler SVB2-TB-1000 / SVB2-TB-1500
Heavy-duty vertical baler for car and truck tyres, making bales of up to 1700 kg.
POA — price on application
Enquire about this machine Client sign-in for prices
Got an old machine? Trade it in towards this one →
Not sure this is the right machine? Try our baler selector →
New machine with a 12-month warranty, serviced and supported by our own engineers.
Made to order: ask us about lead times, options, delivery and installation.
About this machine
A heavy-duty vertical baler for high-rebound material: tyres. It has the force to overcome the rubber's rebound and press tyres into dense bales, saving storage and transport space. As an example, the SVB2-TB-1000 Standard takes 9 strokes to make a bale of around 120–140 car tyres, weighing up to 1200 kg, at a compression ratio of about 12:1.
Tyre bales are also used as a construction material in road foundations, embankment fill, drainage layers, landscaping and other civil engineering work.
Optimised versions add a faster cycle (39 seconds instead of 49 on the TB-1000), double oil filtration and high-efficiency air cooling for the hydraulics, for longer component life and less maintenance.
Features
- Chain bale ejector
- Two split platens with a movable link, protecting the platens from uneven loading
- Retractable retainer claws to stop compacted tyres springing back
- Hydraulic chamber doors for safe, easy opening and closing
- Front and back chamber doors for easy strapping and bale ejection
Typical materials
Car tyres, light and heavy truck tyres, bicycle tyres and motorcycle tyres.
Specification
| Manufacturer | Sinobaler |
|---|---|
| CE marking | CE marked by the manufacturer |
| Warranty | 12 months |
Models & specifications
| Model | SVB2-TB-1000 Standard | SVB2-TB-1000 Optimised | SVB2-TB-1500 Standard | SVB2-TB-1500 Optimised |
|---|---|---|---|---|
| Feed opening (L × H) | 1550 × 700 mm | 1550 × 700 mm | 1800 × 700 mm | 1800 × 700 mm |
| Bale size (L × W × H) | 1550 × 760 × 600–1150 mm | 1550 × 760 × 600–1150 mm | 1800 × 1100 × 700–1400 mm | 1800 × 1100 × 700–1400 mm |
| Bale weight (tyres) | 800–1200 kg | 800–1200 kg | 1200–1700 kg | 1200–1700 kg |
| Motor power | 15 kW | 18.5 kW | 22 kW | 30 kW |
| Number of ties | 5 | 5 | 9 | 9 |
| Cycle time (unloaded) | 49 s | 39 s | 55 s | 30 s |
| Machine weight (approx.) | 5000 kg | 5200 kg | 7500 kg | 7700 kg |
Manufacturer's figures, which can change without notice. Bale weights depend on your material, and bale sizes don't allow for expansion after the bale is ejected. We'll confirm the exact specification with your quote.
